QUALITY ASSURANCE



Certification

The certificate is valid from 2020-11-24 until 2023-11-23 (First certification 2009). Certification ISO 9001:2015.



Download Certification as PDF



Measuring equipment:

To maintain continuously high quality for the parts to be manufactured, we use the following measuring instruments.

Upon customer request, test reports and material and hardening certificates can be provided.



Measuring machine 3D manually controlled
Broun & Sharpe Microl - Val 343 on hard-stone slab
Measuring precision of 0.0050



Measuring machine CNC 3D controlled
CNC coordinate measuring equipment
Mitutoyo CRYSTA – Apex S500
with controlled measuring head and scan function
X = 500 mm, Y = 700 mm, Z = 400 mm



Measuring device with button on hard-stone slab
Mahr Millitron 1240 with button 1340
Measuring precision of 0.0010 mm
Diameter 0 - 150 mm



Wirth profile projector
Magnification between 10 and 50 times
Table size 200 mm x 150 mm
Measuring range 50 mm x 50 mm



Hinze rigid endoscope
Endoscope diameter 16 mm
Endoscope length 150 mm
Viewing direction direct and 90° angle



Altimeters
Mauser KMG 800
on a hard stone plate
Measuring accuracy of 0.0025
X = 1.000 mm, Y = 600 mm, Z = 800 mm
Trimos 500
on a hard stone plate
Measuring accuracy of 0.0030
X = 1.000 mm, Y = 1.000 mm, Z = 500 mm
Hofmann/Grant
on a hard stone plate
Measuring accuracy of 0,0030
X = 1.200 mm, Y = 800 mm, Z = 600 mm



Roughness testing device
Perthen perthometer H4P



Measuring microscope
Mitutoyo 280
Table size 280 x 152



as well as various mechanical measuring devices.
